American Range 60" Horizontal Chicken Broiler – Gas, Countertop
Models AHS-6027 / AHS-6036
Built for high-capacity, all-day production, the American Range horizontal chicken broiler unleashes
200,000 BTU of balanced, radiant heat across five powerful burners. Its open-bottom design
maximises up-draft for cleaner combustion while the round-rod, non-stick grates give perfectly seared,
restaurant-quality results—batch after batch.
Key features
- Five 40,000 BTU/hr. burners deliver consistent heat across the entire 60" cooking surface.
- Round-rod top grates are ideal for spatchcock chickens and help prevent sticking & warping.
- Open bottom grate design encourages continuous draft for efficient fuel use and fast recovery.
- All-stainless-steel exterior cleans quickly and resists corrosion in tough kitchen environments.
- Heavy-duty interior liner protects the cabinet from burn-out, extending equipment life.
- Ships ready for Natural Gas or LP (select at checkout) – 3/4" NPT rear connection.
- Countertop configuration; optional stand or caster kit available for added mobility.
- ETL-Sanitation & cETLus listed for commercial kitchens.
- Designed, engineered, and built in the USA.
Specifications
| Spec |
AHS-6027 |
AHS-6036 |
| Width |
60 in / 1524 mm |
60 in / 1524 mm |
| Depth |
27 in / 686 mm |
36 in / 914 mm |
| Height |
18 in / 457 mm (cabinet only) |
| Burners |
5 (stainless steel) |
| Total Output |
200,000 BTU/hr. (≈59 kW) |
| Gas Manifold Pressure |
NG 5.0" W.C. | LP 10.0" W.C. |
| Gas Connection |
3/4" NPT (rear) |
| Shipping Weight |
370 lb / 167 kg |
400 lb / 181 kg |
| Certifications |
ETL-Sanitation, cETLus |
Installation & clearances
- For non-combustible countertops only. Legs, casters, or a 2" overhang are required for curb-mounting.
- Clearance to combustible walls: 12" (305 mm) sides, 4" (102 mm) rear.
- Must be installed under a ventilation hood in accordance with NFPA 96.
- Specify gas type and altitude (>2,000 ft / 610 m) when ordering.
Warranty
Covered by a two-year limited parts & labor warranty. Burners, upper & lower grates,
and radiants are warranted for 90 days.
Full terms, conditions, and registration instructions can be found in the documentation tab or at
americanrange.com/terms-of-sale.
