DK2 22,000LB JP Hydraulic Winch

Name: DK2 22,000LB JP Hydraulic Winch
Brand: DK2
SKU: 10TJP
Price: 3551.99 USD
Availability: InStock

1 Review

8% Sale

Only left!

Free Delivary

Limited Stocks

In Stock - Ready to be Shipped

~~$3,859.99~~ $3,551.99

Shipping calculated at checkout.

Quantity

Quintity

View full details

SALE ENDS IN

07 HRS

23 MINS

28 SECS

DON'T MISS IT!

Popular Add on

Bundle Offer

$0.00

$100.00

Recently Viewed

Mr. Steam Basic Butler Steam Generator Control ...

$1,048.99 USD

Mr. Steam- 9kW E-Series Steam Shower Generator ...

$2,184.99 USD

Mr. Steam - 9kW Steam Bath Generator Package - ...

$3,286.99 USD

Mr. Steam- 10kW E-Series Steam Shower Generator...

$2,508.99 USD

Mr. Steam - 12kW E-Series Steam Shower Generato...

$2,753.99 USD

Mr. Steam- Butler Steam Generator Control Kit /...

$1,652.99 USD

Mr. Steam - 7.5kW E-Series Steam Shower Generat...

$2,049.99 USD

Mr. Steam - 5kW E-Series Steam Shower Generator...

$1,469.99 USD

Mr. Steam- Butler Steam Generator Control Kit /...

$1,669.99 USD

Mr. Steam- 7.5kW Steam Bath Generator Package -...

$3,150.99 USD

Mr. Steam- 9kW Steam Bath Generator Package - R...

$3,286.99 USD

Mr. Steam- 9kW Steam Bath Generator Package - S...

$3,370.99 USD

Mr. Steam- 7.5kW Steam Bath Shower Generator Pa...

$3,146.99 USD

Mr. Steam- 7.5kW Steam Bath Generator Package -...

$3,028.99 USD

Mr. Steam- 7.5kW Steam Bath Generator Package -...

$3,146.99 USD

MX4EC1 - Max 20kW E-Series Steam Shower Generat...

$4,038.99 USD

MSBUTLER1SQ-MB - Butler Steam Generator Control...

$1,670.99 USD

Mr. Steam MSBUTLER1RD-BN - Butler Steam Generat...

$1,670.99 USD

Wen WEN TF1300iX 13,000-Watt 120V/240V Tri-Fuel...

$2,115.99 USD

WEN GN875iX 8750-Watt RV and Transfer-Switch-Re...

$1,103.99 USD

WEN GN625iX 6250-Watt RV and Transfer-Switch-Re...

$988.99 USD

WEN DF400iX Super Quiet 4000-Watt Dual Fuel RV-...

$984.99 USD

WEN TF1450X 14,500-Watt 120V/240V Tri-Fuel Gene...

$919.99 USD

WEN DF452iX Super Quiet 4500-Watt Remote Electr...

$919.99 USD

WEN 56400iX Super Quiet 4000-Watt RV-Ready Elec...

$919.99 USD

WEN GN9500X 9500-Watt 420cc Transfer-Switch and...

$843.99 USD

WEN TF1450 14500-Watt 120V/240V Tri-Fuel Genera...

$827.99 USD

WEN GN875i 8750-Watt RV and Transfer-Switch-Rea...

$827.99 USD

WEN DF451i Super Quiet 4500-Watt Electric Start...

$809.99 USD

WEN DF623X 6250-Watt 120-Volt/240-Volt Dual Fue...

$799.99 USD

WEN DF1100X 11,000-Watt 120V/240V Dual Fuel Por...

$781.99 USD

WEN DF450i Super Quiet 4500-Watt Dual Fuel RV-R...

$763.99 USD

WEN 56450iX Super Quiet 4500-Watt RV-Ready Port...

$763.99 USD

WEN 56455i Super Quiet 4500-Watt RV-Ready Porta...

$762.99 USD

WEN DF680iX Quiet 6800-Watt Dual Fuel RV-Ready ...

$739.99 USD

WEN DF1100T 11,000-Watt 120V/240V Dual Fuel Por...

$735.99 USD

WEN 56450i Super Quiet 4500-Watt RV-Ready Porta...

$735.99 USD

WEN 56480iX Quiet and Lightweight 4800-Watt RV-...

$726.99 USD

WEN DF480iX Quiet and Lightweight 4800-Watt Dua...

$689.99 USD

WEN 56380i Super Quiet 3800-Watt RV-Ready Porta...

$643.99 USD

WEN DF8000X 8000-Watt 120V/240V Dual Fuel Porta...

$611.99 USD

WEN DF475X 4,750-Watt 120V/240V Dual Fuel Porta...

$606.99 USD

WEN 56477i Quiet and Lightweight 4800-Watt RV-R...

$584.99 USD

WEN DF402iX RV-Ready 4000-Watt Dual Fuel Open F...

$565.99 USD

WEN DF360iX Quiet and Lightweight 3600-Watt Dua...

$563.99 USD

WEN 56360iX Quiet and Lightweight 3600-Watt RV-...

$560.99 USD

WEN DF430X 4375-Watt Dual Fuel Portable Generat...

$558.99 USD

WEN 56432iX 4500-Watt Inverter Generator, RV-Re...

$551.99 USD

WEN GN400iX RV-Ready 4000-Watt Open Frame Inver...

$537.99 USD

WEN 56235iX Super Quiet Ultra Lightweight 2350-...

$528.99 USD

DK2 22,000LB JP HYRDAULIC WINCH

THE JP SERIES WINCHES HAVE BEEN DEVELOPED FOR THE PROFESSIONAL OPERATOR.

BUILT SPECIFICALLY FOR MILITARY USE & ABLE TO WITHSTAND EXTREME CLIMATES AND TEMPERATURES.

These winches have been designed to ensure that as a part of an installation solution they can meet the requirements of EN 14492 : 1. Superb heavy duty winches supplied complete with balance valve, cable and heavy duty tensioner. Standard features include air operated clutch, high precision 2 stage planetary gearing and a rugged high torque motor. The ultimate winch for heavy recovery and commercial applications.

Features

Rugged high torque motor
2 stage planetary gearing
Complete with balance valve
Air operated freespool
Rugged and compact for long life
Heavy duty steel cast frame
Rope and tensioner as standard

Specification

ITEM NUMBER
10TJP

RATED LINE PULL
22000 LBS (10000 KG)

GEARING
39:1

BRAKING ACTION
AUTO HYDRAULIC

DRUM SIZE - DIAMETER x LENGTH
138 x 316mm (5.42 x 12.44')

CABLE - DIAMETER x LENGTH
15mm x 48m (0.59' x 157')

DIMENSIONS
830 x 390 x 320mm (32.6 x 15.3 x 12.6')

MOUNTING PATTERN
431 x 64 / 192mm (16.9 x 2.5 / 7.5')

WEIGHT
165 KG (363 LBS)

CERTIFICATION
CE CERTIFIED




LAYER OF ROPE / CABLE
LINE PULL: LBS (KGS)

1
22046 (10000)

2
16889 (7661)

3
14615 (6630)

4
12881 (5843)




LINE PULL: LBS (KGS)
LINE SPEED FT/MIN (M/MIN)
FLOW L/MIN • PRESSURE MPA

0
5.9 (1.8)
15 • 25

4000 (1814)
11.7 (3.6)
30 • 42

8000 (3629)
19.6 (6.0)
50 • 85

15000 (6804)
23.6 (7.2)
60 • 140

22046 (10000)
29.7 (9.0)
75 • 175

Manual

Manual Instruction

Technical Diagram

Brochure

Order shipment preparation takes 3 days. Once shipped orders usually takes 2 weeks to be delivered. These are estimations; can be delayed for reasons beyond our control. You can always contact us to know the exact time once you placed an order with us. Have a look at our

ITEM NUMBER	10TJP
RATED LINE PULL	22000 LBS (10000 KG)
GEARING	39:1
BRAKING ACTION	AUTO HYDRAULIC
DRUM SIZE - DIAMETER x LENGTH	138 x 316mm (5.42 x 12.44')
CABLE - DIAMETER x LENGTH	15mm x 48m (0.59' x 157')
DIMENSIONS	830 x 390 x 320mm (32.6 x 15.3 x 12.6')
MOUNTING PATTERN	431 x 64 / 192mm (16.9 x 2.5 / 7.5')
WEIGHT	165 KG (363 LBS)
CERTIFICATION	CE CERTIFIED

LAYER OF ROPE / CABLE	LINE PULL: LBS (KGS)
1	22046 (10000)
2	16889 (7661)
3	14615 (6630)
4	12881 (5843)

LINE PULL: LBS (KGS)	LINE SPEED FT/MIN (M/MIN)	FLOW L/MIN • PRESSURE MPA
0	5.9 (1.8)	15 • 25
4000 (1814)	11.7 (3.6)	30 • 42
8000 (3629)	19.6 (6.0)	50 • 85
15000 (6804)	23.6 (7.2)	60 • 140
22046 (10000)	29.7 (9.0)	75 • 175
