American Range Gas Griddles - ARTG-24-24
60,000 BTU | 18 kW | ETL Listed | Made in USA
Bring steak-house sear and breakfast-rush speed to any cookline with the American Range ARTG-24-24. This compact, 24-inch thermostatic griddle pairs a hefty 1-inch steel plate with precision heat control and a rugged stainless-steel body—engineered and built in California for the rigors of the busiest commercial kitchens.
Features
- 1" thick, polished steel griddle plate for superior heat retention and recovery.
- (2) 30,000 BTU U-shaped burners (one every 12") distribute heat evenly edge-to-edge.
- Modulating thermostatic controls with standing pilots maintain 250 °F – 500 °F (121 °C – 260 °C).
- 24" cooking depth plus a 3" welded splash guard to contain grease and food debris.
- Full stainless-steel exterior, 3" grease trough, and removable grease pan for quick cleanup.
- 4" adjustable stainless legs keep the unit level and NSF-compliant for sanitation.
- ¾" NPT rear gas connection; field convertible to Natural Gas or LP (specify at order).
Specifications
| Model |
ARTG-24-24 |
| Energy Type |
Natural Gas or Propane Gas |
| Total Input |
60,000 BTU/hr (18.0 kW) |
| Cooking Surface |
24" W × 24" D (610 mm × 610 mm) |
| Overall Dimensions |
24" W × 35" D × 17" H (610 mm × 889 mm × 432 mm) |
| Plate Thickness |
1" (25 mm) smooth polished steel |
| Burners |
2 U-shaped, 30,000 BTU each |
| Temperature Range |
250 °F – 500 °F (121 °C – 260 °C) |
| Gas Connection |
¾" NPT rear; 5.0" W.C. Natural | 10.0" W.C. LP |
What our Experts Think
Q&A
Q: What is the American Range ARTG-24-24 used for?
A: The American Range ARTG-24-24 is a commercial countertop gas griddle designed for restaurants, diners, and foodservice kitchens that need consistent flat-top cooking for breakfast items, burgers, sandwiches, and grilled entrées.
Q: What type of heat system does the ARTG-24-24 use?
A: It uses high-efficiency U-shaped burners with thermostatic control for precise temperature regulation and even heat distribution across the cooking surface.
Q: How powerful is the ARTG-24-24?
A: It delivers a total of 60,000 BTU, providing strong heat output and fast recovery for continuous commercial cooking.
Q: What is the cooking surface size?
A: The unit features a 24-inch wide by 24-inch deep cooking surface, ideal for compact yet high-output kitchen setups.
Q: What type of griddle plate is used?
A: It includes a 1-inch thick polished steel griddle plate that ensures excellent heat retention and even cooking performance.
Q: Does it allow temperature control per zone?
A: Yes, each burner is thermostatically controlled, allowing multiple heat zones for different foods at the same time.
