SCM AR16 Elite 4'x4' CNC Router - AX9-AR16ELITEc
Axiom Precision offers a wide range of machines to address nearly any small-format CNC application. Each machine has been thoughtfully designed and rigorously tested in their Columbus, Ohio facility. These CNCs are engineered from the ground up like a large machine, but they will fit comfortably in your shop. Count on Axiom for accuracy, repeatability and speed without the use of any complex software.
The Axiom Precision AutoRoute Elite CNC router represents the most advanced technology that is primarily found on machines in industrial shops. They offer the speed, torque, and precision which can only be found in servo-driven machines. Cut at up to 320 IPM while maintaining repeatability of .05mm!
The Elite Series CNC routers have a full 8'' Z travel capacity and a quiet yet powerful 3HP electro-spindle with an integrated liquid cooling system. All Elite Series routers utilize 20mm precision ball screws, massive prismatic guides, a robust steel frame, and an interlocking aluminum table. In addition, the integrated MDF spoil boards promise you the all precision you need, since they can easily be milled flat for a true perpendicular surface to the spindle.
There is no need to attach your CNC router to your computer to operate it. Simply transfer your file to the controller via a USB storage device. The hand-held RichAuto B58 DSP controller is powerful, easy to use, and 4th-axis ready.
All Axiom machines come with lifetime technical support. Whether it’s a software or technical question, or just a challenging application, Axiom is there to help — regardless of how long you’ve owned your machine. No invoices, no expiration dates.
-
Furniture Making: Whether you’re simply cutting out 2D furniture components, producing an accent inlay, or an ornate 3D wood appliqué, the applications for a CNC router within the woodworking trade are nearly countless.
-
Fabrication: Need to produce a unique component? Wood, Aluminum, Brass, Composites, Phenolic, Foam, Plastic - If it can be cut with a spinning bit, Axiom Precision can produce it quickly and accurately.
-
Sign Making: The ability to use a CNC machining center to carve letters and design elements into wood, plastic and aluminum has transformed the sign industry. Axiom Precision offers the machines, software, and accessories to produce nearly any sign you can imagine.
-
3D Carving: Axiom Precision’s capacity and accuracy make each machine a 3D carving powerhouse. From large three dimensional objects, to fine furniture accents, you’ll quickly produce accurate 3D carvings.
-
Prototyping: Axiom Precision offers a small, yet accurate machine to produce one-off components and prototypes.
-
Millwork: Reproducing historic architectural components is a snap with Axiom Precision. Brackets, capitals, arches, corbels, moldings and more can all be produced with ease.
Features
-
Interlocking Aluminum table: The most rigid, flat and stable surface around
-
Structural Steel Frame: Every machine is built on this massive structure
-
Cast Gantry Supports: Complex gravity castings virtually eliminate flex
-
Proximity Sensors: These magnetic sensors act as your CNC's eyes
-
Ball Screws: Found on every Axiom Precision machine
-
Onboard Cooling System: No buckets, no hoses, no aquarium pumps. No drama
-
Linear Guideways: Minimal friction. Maximum accuracy
-
Industrial DSP Controller: No complex software. The hand-held controller is powerful yet easy to use
-
Cable Track Chain: Stress-free movement of hoses and cables
-
High Torque Steppers & Servos: Fast, repeatable positioning of all axes
-
Tool Touchoff Device: Measure your bit length quickly and accurately
-
Industrial Data Connectors: No weak links
What our Experts Think
-
Engineered for professional woodworking, sign making, cabinetry, and fabrication, the SCM AR16 Elite 4' x 4' CNC Router delivers industrial-grade accuracy in a compact workshop footprint.
-
The servo-driven motion system and precision ball screws provide exceptional repeatability, smooth operation, and reliable cutting performance for demanding production work.
-
A powerful 3HP liquid-cooled spindle maintains consistent performance during extended machining sessions while supporting a wide range of materials and applications.
-
Its spacious 4' x 4' cutting area is ideal for furniture components, custom signage, architectural millwork, 3D carving, and prototype development.
-
The rugged all-welded steel frame, precision linear guideways, and industrial controller help maximize accuracy, productivity, and long-term durability.
Q&A
Q: What is the SCM AR16 Elite 4' x 4' CNC Router (AX9-AR16ELITE)?
A: A professional-grade 4' x 4' CNC router featuring servo-driven motion, a rigid steel frame, and precision ball screws for high-speed, highly accurate machining.
Q: What materials can the AR16 Elite machine cut?
A: It is ideal for wood, MDF, plastics, foam, composites, aluminum, brass, sign-making materials, and prototype production.
Q: What spindle does the machine include?
A: The AR16 Elite comes equipped with a 3HP (2.2kW) liquid-cooled ER20 electro-spindle with variable speeds up to 24,000 RPM.
Q: How accurate is the AR16 Elite CNC Router?
A: It delivers repeatability of ±0.05 mm (±0.00197"), making it ideal for cabinetry, furniture, engraving, and precision production work.
Q: What is the cutting area and Z-axis travel?
A: The machine offers a 48" × 48" cutting area with 7.48" of Z-axis travel, providing ample capacity for large woodworking and fabrication projects.
Q: Does the CNC router require a dedicated computer?
A: No. The RichAuto B58 DSP controller allows standalone operation via USB file transfer, eliminating the need for a connected computer.
Q: Why choose the AR16 Elite AX9-AR16ELITE?
A: Its servo-driven performance, industrial-grade construction, liquid-cooled spindle, and precision motion system make it an excellent choice for professional woodworking, sign making, fabrication, and CNC production environments.
Maintenance Tips
- Clean the table, spoilboard, guideways, and gantry after each use to prevent dust and chip buildup.
- Lubricate precision ball screws and linear guideways regularly for smooth, accurate motion.
- Check the liquid-cooled 3HP spindle system and coolant level to prevent overheating.
- Inspect collets, tool holders, and cutting bits for wear; replace damaged tooling promptly.
- Surface the MDF spoilboard as needed to maintain a flat and accurate cutting surface.
- Verify tool touch-off calibration and machine zero points for consistent machining accuracy.
- Inspect cables, connectors, and cable tracks for wear, damage, or loose connections.
- Tighten accessible fasteners and inspect the steel frame and gantry for vibration-related loosening.
- Keep proximity sensors clean and free of debris to ensure reliable positioning.
- Maintain an efficient dust collection system to protect mechanical and electronic components.
- Monitor spindle noise, vibration, and cutting performance to identify maintenance needs early.
- Store and operate the machine in a clean, dry, temperature-controlled environment.
