Beckhoff Basic CPU Module - CX2030
The CX2030 Basic CPU Module features a robust 1.5 GHz Intel® Core™ i7 dual-core CPU, offering reliable performance without fan or rotating components. It i
ncludes 2 GB of standard RAM, expandable to 4 GB, and boots from a CFast flash memory card.
Standard configuration comprises two independent Gbit Ethernet interfaces, four USB 2.0 ports, and a DVI-I interface. A 128 kB NOVRAM ensures persistent data storage in the absence of UPS. Optional fieldbus or serial interfaces can be integrated, with connectivity for additional CX2000 family components via multi-pin terminals.
Specifications
| Part Number |
CX2030-0125-3001 |
| Category |
Computer |
| Subcategory |
Communication Card Processor |
| Processor |
Intel® Core™ i7 2610UE 1.5 GHz, 2 cores |
| Flash memory |
20 GB or 40 GB CFast flash card (depending on OS), expandable |
| Main memory |
2 GB DDR3 RAM (expandable to 4 GB ex factory) |
| Persistent memory |
128 kB NOVRAM integrated |
| Interfaces |
2 x RJ45 10/100/1000 Mbit/s, 1 x DVI-I, 4 x USB 2.0, 1 x optional interface |
| Cooling |
Passive cooling, optionally with active cooling ex factory |
| Diagnostics LED |
1 x power, 1 x TC status, 1 x flash access, 2 x bus status |
| Clock |
Internal battery-backed clock (exchangeable battery) |
| Control software |
TwinCAT 2 runtime, TwinCAT 3 runtime (XAR) |
| I/O connection |
Via power supply module (E-bus or K-bus, automatic recognition) |
| Power supply |
24 V DC (-15%/+20%) |
| Max. power consumption |
27 W |
| Dimensions (W x H x D) |
144 mm x 99 mm x 91 mm |
| Weight |
Approx. 1165 g |
| Relative humidity |
95%, no condensation |
| Operating/storage temperature |
-25…+60°C / -40…+85°C |
| EMC immunity/emission |
Conforms to EN 61000-6-2/EN 61000-6-4 |
| Vibration/shock resistance |
Conforms to EN 60068-2-6/EN 60068-2-27 |
| Protection rating |
IP20 |
What our Experts Think
-
A powerful industrial automation controller, the Beckhoff CX2030 Basic CPU Module is designed for demanding PLC, motion control, and real-time automation applications.
-
Intel Core i7 processing power delivers strong performance, allowing complex control tasks, visualization, and data processing to run efficiently.
-
Built on Beckhoff’s PC-based control platform, it integrates seamlessly with TwinCAT for advanced PLC programming, motion control, and industrial IoT applications.
-
Compact DIN-rail design saves cabinet space, making it ideal for machine builders and industrial systems where reliability and efficiency matter.
-
Modular CX20xx architecture offers flexibility, allowing users to expand with I/O modules, communication interfaces, and additional functionality as system needs grow.
-
Industrial-grade reliability makes it suitable for 24/7 operation, supporting applications such as manufacturing lines, robotics, packaging equipment, and process automation.
Q&A
Q: What is the Beckhoff Basic CPU Module CX2030?
A: The Beckhoff CX2030 is a compact embedded PC/PLC controller designed for industrial automation, machine control, and EtherCAT-based systems.
Q: What are the key features of the CX2030?
A: It includes a high-performance Intel® Celeron® processor, fanless design, modular I/O expansion, and compatibility with TwinCAT automation software.
Q: What applications is the CX2030 used for?
A: It is commonly used in machine automation, motion control, process control, data acquisition, and industrial networking applications.
Q: Does the CX2030 support EtherCAT?
A: Yes. The CX2030 is designed for integration with EtherCAT terminals and Beckhoff distributed I/O systems.
Q: Why choose an embedded PLC like the CX2030?
A: It combines PLC functionality and PC performance in a compact industrial controller, saving space while providing flexible automation control.
Q: Is the CX2030 suitable for industrial environments?
A: Yes. Its fanless construction and modular design make it suitable for reliable 24/7 industrial operation.
Maintenance Tips
- Keep ventilation openings free from dust and debris.
- Check power, I/O, and communication connections regularly.
- Monitor operating temperature and ensure proper airflow.
- Protect the module from moisture, vibration, and excessive heat.
- Back up PLC programs and configuration files regularly.
- Keep TwinCAT software and system components updated.
- Inspect mounting and DIN rail connections for stability.
- Store and operate in a clean industrial environment.
