Air Lift ICON Vehicle Dynamics Stage 7 Suspension System 6" Lift With Tubular UCA | 2022-2026 Toyota Tundra - ICOK53277T

Air Lift ICON Vehicle Dynamics Stage 7 Suspension System 6" Lift With Tubular UCA | 2022-2026 Toyota Tundra - ICOK53277T

TheYotaGarage is proud to offer the ICON Vehicle Dynamics Stage 7 Suspension System 6" Lift with Billet UCA for your 2022+ Toyota Tundra. The ICON Vehicle Dynamics Stage 7 Suspension System 6" Lift with Tubular UCA offers superior damping and vehicle control with up to 40% increased front wheel travel over stock. It features 2.5 Series front coilovers and rear shocks with remote reservoirs, CDC Valves for 10 settings of damping adjustment, and tubular front UCAs. The system also maintains the factory track width and optimizes suspension geometry for nearly no bump steer. Fits 37" tires with full articulation.

Features

• 2.5 Series front coilovers and rear shocks with remote reservoirs for superior damping and vehicle control along with improved shock cooling
• All shock absorbers equipped with CDC Valves for 10 settings of compression damping adjustment, from soft to hard
• System allows for up to 40% increase in front wheel travel over stock without overstressing OE components
• Optimized design to fit 37" tires with full articulation (larger tires may fit but fender trimming and modifications will be required)
• Maintains factory track width
• Optimized suspension geometry nearly eliminates the bump steer found in stock Tundras
• Adjustable front ride heights from 5-6” of front lift over stock (up to 6" of lift with only 4" of crossmember drop)
• Tubular UCAs with Delta Joint Pro for added strength, durability, and caster correction for improved drivability
• Patented Delta Joint Pro (U.S. Pat. 10,731,700) provides improved durability and serviceability with 90 degrees of total articulation
• Single piece high-strength ductile iron steering knuckles with built-in 4" drop
• Hight clearance front crossmembers and front skid plate, CNC Laser Cut and brake-formed from 1/4-inch steel plate
• Included sway bar drop brackets reduce bind in OE sway bar links
• Front and rear heavy-duty bump stop brackets
• High angle outer tie-roads feature durable, metal on metal greaseable tie rod ends
• ICON engineered custom triple rate rear coil springs provide progressive spring rates for a comfortable ride on-road as well as stability and control during aggressive off-road driving
• Billet rear upper and high clearance lower links improve rear end articulation and allow on-vehicle adjustment for different ride heights and pinion angles using ICON's double adjuster system
• Billet rear lower links have replaceable nylon rock sliders to protect the links from trail damage
• On-vehicle adjustable billet rear track bar properly centers rear axle while also improve rear suspension performance
• Improved rear sway bar links and mounts, and rear track bar bracket to reduce bind in the rear suspension
