Launch X-431 ADAS Hyundai AVM Target - LNCH-LAC04-31
Features
-
Brand: Launch Tech USA
-
MPN: LAC04-31
What our Experts Think
-
Hyundai-Specific AVM Calibration Precision: Designed for accurate calibration of Hyundai Around View Monitor (AVM) systems after camera, bumper, or body repairs.
-
OEM-Level 360° Restoration: Ensures factory-spec surround-view accuracy for safe and reliable parking assistance performance.
-
Launch X-431 ADAS Integration: Fully compatible with Launch X-431 ADAS platforms for guided, structured calibration workflows.
-
Essential Post-Repair Tool: Required after rear camera replacement, collision repair, or any work affecting camera alignment.
-
High-Precision Target Patterning: Engineered reference markings ensure consistent recognition and repeatable calibration results.
-
Improves Driver Assistance Accuracy: Helps eliminate stitching errors, distorted guidelines, and misaligned parking visuals.
-
Workshop-Ready Durability: Built for repeated professional use in busy ADAS calibration and collision repair environments.
-
Efficient Calibration Workflow: Streamlined setup reduces service time while maintaining strict Hyundai OEM standards.
Q&A
Q: What is the Launch X-431 ADAS Hyundai AVM Target LNCH-LAC04-31 used for?
A: It is a precision ADAS calibration target used to align Hyundai Around View Monitoring (AVM) 360° camera systems after repair, replacement, or collision work.
Q: Which vehicles is it compatible with?
A: It is designed for Hyundai Motor Company vehicles equipped with factory 360° surround view (AVM) systems.
Q: Is it a standalone tool?
A: No, it is used with the Launch X-431 ADAS calibration frame and diagnostic tablet for accurate OEM-level calibration.
Q: Why is AVM calibration important?
A: It ensures correct 360° image stitching, accurate parking assistance, and restores factory camera alignment and safety performance.
Q: What makes the LNCH-LAC04-31 important?
A: It provides Hyundai-specific target geometry required for precise AVM calibration across compatible models.
Maintenance Tips
-
Keep surface clean: Use a soft microfiber cloth to remove dust, fingerprints, and oil for accurate AVM calibration.
-
Avoid scratching the pattern: Do not use abrasive materials or harsh chemicals that can distort printed markers.
-
Store flat in protective case: Prevent bending, warping, or pressure damage that affects geometric accuracy.
-
Protect from heat & sunlight: UV exposure can fade calibration markings and reduce detection reliability.
-
Ensure pattern clarity before use: Verify all reference points are sharp, visible, and undamaged.
-
Use on level ground only: Uneven placement can cause incorrect 360° surround view calibration.
-
Handle with clean hands/gloves: Prevent smudges or oil transfer that interfere with camera recognition.
-
Inspect regularly: Replace immediately if any peeling, fading, or structural deformation appears.
