BNC to 4 mm Test Leads: Test lead of a male BNC connector to (2) 4mm connectors. It is a kind of special line for assisting the Scope box to test various types of signals.4mm connectors are code din two colors. Black (earth wire)and red (positive pole which should be connected with the 6-way Breakout Leads).

6-way Breakout Leads: Moreover, it can also work with the 20:1 Attenuator. With these 6-way leads, you will be able to test most of the sensors and actuators on all makes and models or vehicle, including MAP, temperature, throttle position and airflow sensors, fuel pumps, primary ignition circuits and fuel injectors.

USB Cable: Connects the Scope box and diagnostic tool so that the sampled signal can be displayed on the diagnostic tool.

Battery Clamps Cable: To supply power to the Scope box through connection to vehicle's battery.

20:1Attenuator: It allows the Scope box to measure fuel injector and primary Ignition wave forms.

'Note: Please note this attenuator should be not used for any high voltage measurements other than fuel injectors and primary ignition.

Secondary Ignition Pick-up: This ignition pick-up is applied din the following Situations: Secondary-distributor ignition analysis, Secondary-simultaneous ignition analysis and Secondary-direct ignition analysis.

COP (Coil-on-Plug) Extension Cord: Coil-on-Plug extension cord (including earth cord) allows you to take accurate secondary ignition measurements on secondary-direct (Coil-on-Plug) ignition systems. It can be applied in the condition that there are no, or limited access to any spark plug leads.

Crocodile Clips: Designed to connect the bare terminals or leads.

Back Probe Pins Suite: They are mainly used for piercing the insulation of wires to ' allow for automotive electrical measurements without i causing damage to the wires. Additionally they can be used as pin-tip probes while working with small circuit boards.

What our Experts Think

• Enhances Diagnostic Scope Capabilities – Designed to complement compatible diagnostic scope equipment by providing the accessories needed for more effective signal testing and analysis.
• Improves Testing Flexibility – Additional probes, leads, and connectors help technicians access a wider range of circuits, sensors, and electrical components.
• Supports Accurate Measurements – Using the correct accessories can improve signal quality and testing reliability when diagnosing complex electrical faults.
• Ideal for Advanced Diagnostics – Particularly valuable for technicians performing waveform analysis, sensor testing, and in-depth electrical troubleshooting.
• Reduces Setup Time – Having a dedicated accessory kit readily available helps streamline diagnostic procedures and improve workshop efficiency.
• Professional Workshop Essential – A practical addition for repair facilities that regularly use oscilloscopes or scopebox diagnostic equipment.

Q&A

Q: What is the Launch O2-1 Accessory Kit?
A: The O2-1 Accessory Kit is a diagnostic accessory package designed to enhance the functionality and testing capabilities of compatible Launch diagnostic equipment.

Q: What is the purpose of this accessory kit?
A: It provides additional testing accessories and connection tools that help technicians perform more comprehensive vehicle diagnostics.

Q: Is the O2-1 Accessory Kit compatible with all diagnostic devices?
A: No, it is intended for use with compatible Launch diagnostic tools and testing equipment.

Q: How does this accessory kit improve diagnostics?
A: It expands testing options, improves signal access, and helps technicians perform more accurate electrical and component analysis.

Q: Is this kit suitable for professional workshops?
A: Yes, it is designed for automotive repair facilities, diagnostic specialists, and professional technicians.

Q: Can it assist with electrical troubleshooting?
A: Yes, the included accessories help support testing of vehicle electrical systems, circuits, and related components.

Q: Does the kit help improve workflow efficiency?
A: Yes, having the proper testing accessories readily available can streamline diagnostic procedures and reduce troubleshooting time.

Q: Who is the Launch O2-1 Accessory Kit ideal for?
A: It is ideal for automotive technicians, diagnostic professionals, repair shops, and service centers using compatible Launch diagnostic systems.
