For nearly one hundred years, Powermatic has been dedicated to woodworkers. As a market leader in woodturning, Powermatic is proud to offer the powerful PM2014 model Lathe. Only requiring a 115V single phase power source the inverter delivers 1hp, 230V, 3PH performance, giving users maximum speed with minimum input.
With a capacity of 14" swing over bed and 20" between centers which can be increased with the optional 13" bed extension. Premium sliding headstock and removable tailstock feature allows greater clearance when positioned at the end of the bed for outboard turning. Robust cast iron bed reduces vibration when turning larger and rougher pieces.
Digital Indexing and spindle speed readout are clearly visible on the magnetic repositionable control box. The new ergonomic stand adjusts from centerline to floor from 34 inches to 46 inches allowing the PM2014 to be accessible to users of a range of heights.
Features
Acme threads on tail stock for smoother operation and longevity
Attached tool caddie allows convenient access to centers, wrenches, and accessories
Banjo features a non-marring, pinch style clamp for solid tool rest placement
Chrome-trimmed hand wheels are ergonomic for a comfortable feel
Includes 8 inch tool rest with 1 inch post
Lathe easily disassembles for better portability
Main power disconnect on rear of headstock lock out for safety
24 positive locking indexing position, displayed on the moveable magnetic control box, simplifies the indexing process
Variable speeds from as low 15RPMs to as high as 3600RPMs
With constant monitoring of the motor the inverter keeps torque consistent.
Specifications
Style (Type)
Benchtop
Bed Construction
Cast Iron
Distance Between Centers
19-1/4"
Gross Weight
205 lbs.
Net Weight
183 lbs.
Weight
183 lbs.
Headstock Movement
Sliding
Motor Amps
3 Amps
Motor Power
1 HP
Motor Phase
1 Phase
Motor Voltage
230V
Prewired Voltage
115V
Number of Indexing Positions
24
Outboard Turning
Yes
Overall Dimensions (L × W × H)
52" × 24" × 18"
Shipping Dimensions (L × W × H)
33.25" × 18.9" × 22.83"
Quill Taper
MT2
Spindle Taper
MT2
Spindle Thread
1-1/4" / 8 TPI
Speed Range
15–3600 RPM
Swing Over Bed
14-1/4"
Swing Over Tool Rest Base
10-3/4"
Video
What our Experts Think
The Powermatic PM2014 Lathe - PM9-1792014 is a compact professional woodturning lathe designed for craftsmen who need precision, portability, and reliable performance in a smaller footprint.
The 1HP motor with variable-speed control provides smooth speed adjustments and dependable torque for bowls, spindles, pens, and detailed turning projects.
The 14" swing over bed and 20" turning capacity offer excellent versatility for a benchtop lathe while keeping the machine space-efficient.
The sliding headstock design allows better positioning and improved access for outboard turning applications.
The heavy cast iron bed construction helps reduce vibration, improving stability, control, and surface finish during turning operations.
The magnetic repositionable control box with digital display keeps spindle speed and indexing information easy to view while working.
The 24-position spindle indexing system supports accurate decorative turning, layout work, and repeatable detailing.
The modular design and removable components make this lathe easier to transport, store, and adapt to different workshop setups.
Expert verdict: A high-quality compact lathe that delivers Powermatic-level accuracy and durability, making it an excellent choice for serious hobbyists, small shops, and precision turners
Q&A
Q: What is the Powermatic PM2014 Lathe? A: The Powermatic PM2014 is a compact professional woodturning lathe designed for bowls, spindles, and precision turning projects.
Q: What motor does the PM9-1792014 use? A: It features a 1 HP motor with variable-speed control, delivering smooth and reliable performance for woodworking applications.
Q: What is the turning capacity of this lathe? A: It provides a 14-1/4" swing over the bed and 19-1/4" distance between centers for versatile turning work.
Q: Does the PM2014 have variable speed control? A: Yes, the electronic variable-speed system allows users to adjust spindle speed for different materials and projects.
Q: What is the benefit of the sliding headstock? A: The sliding headstock improves access and control, especially for outboard turning applications.
Q: Does it include spindle indexing? A: Yes, the PM2014 features 24-position spindle indexing for decorative turning and repeatable layouts.
Q: Is the PM2014 stable during operation? A: Yes, the heavy cast iron bed construction helps reduce vibration and improves turning accuracy.
Q: Is this lathe suitable for small workshops? A: Yes, its compact design and modular construction make it ideal for shops with limited space.
Q: Does it include user-friendly controls? A: Yes, the repositionable control box provides easy access to spindle speed and indexing information.
Q: Why choose the Powermatic PM2014 Lathe? A: It combines professional-grade accuracy, compact size, variable-speed control, and durable construction for dependable woodturning performance.
Maintenance Tips
Clean wood chips, dust, and debris regularly from the lathe bed, spindle area, and work surfaces.
Keep the lathe bed and ways clean and lightly lubricated for smooth movement.
Inspect the spindle, bearings, and drive components for unusual noise, vibration, or wear.
Clean and maintain the tailstock quill and tool rest for accurate adjustments.
Check belts and pulleys regularly for proper tension, alignment, and wear.
Lubricate moving parts, locking mechanisms, and adjustment points as needed.
Inspect chucks, centers, and accessories for damage or loose fittings.
Keep the motor, switches, and electrical components free from dust buildup.
Tighten bolts, handles, and mounting hardware periodically for stability.
Store the lathe in a clean, dry workshop environment to prevent rust.
